In this short post we look at how we got rid of the Swift packages in our bevy_ios_* crates.
Most of them we used to ship in a tandem: a Rust crate on crates.io and a Swift package that you had to add to your xcode project via SPM. Over the last weeks we released them again, this time without that second half.
Installing them is now just cargo add.
Why?
The language barrier itself did not go anywhere, we still cross it on every call. What changed is that we do not have to build and ship that crossing ourselves anymore.
The platform side lived in that package, written in Swift or Objective-C, and rust could only reach into it through C symbols. So every crate came with its own hand-written bridge and over the years we ended up with four different ones:
bevy_ios_safearea: Swift functions exported as C symbols via@_cdeclbevy_ios_alertsandbevy_ios_review: hand-written Objective-C behind a C headerbevy_ios_notifications: protobuf messages serialized across the C ABIbevy_ios_gamecenterandbevy_ios_iap: swift-bridge plus a prebuilt.xcframework
They all had the same downsides:
- every one of our READMEs started with the xcode step of adding the SPM package, screenshot included
- the crate version and the package version had to match, that is why our install instructions said things like
bevy_ios_gamecenter = { version = "=0.6.0" }. Get it wrong and you find out at link time. - the swift-bridge crates also needed CI to build an
.xcframework, zip it, hash it and attach it to a GitHub release on every version - no simulator builds,
swift-bridgepulls inrust-bindgenwhich brokeaarch64-apple-ios-simfor us
What replaced it
All of it is now objc2 and its generated framework bindings: objc2-ui-kit, objc2-user-notifications, objc2-game-kit and objc2-store-kit. Apple's frameworks are Objective-C anyway, and unlike Swift, Objective-C has a dynamic runtime you can bind against generically: selectors, type encodings, objc_msgSend. That is what objc2 does for us under the hood, once, for every framework. The bridge is a dependency now instead of a second thing we ship.
Mads Marquart, who maintains objc2, gave a talk about exactly this at our Bevy Meetup #13: Bevy on iOS - in pure Rust. Well worth a watch.
Our existing bevy_ios_app_delegate crate was built that way already. Our previous post on iOS deep-linking goes into detail here.
Lets look at the smallest crate first. bevy_ios_safearea used to be four Swift functions like this one:
@_cdecl("swift_safearea_top")
public func safeareaTop(view: UnsafeRawPointer) -> Float32 {
let view = Unmanaged<UIView>.fromOpaque(view).takeUnretainedValue()
return Float32(view.safeAreaInsets.top);
}
// ... and three more for bottom, left, right
plus their extern "C" declarations on the rust side, plus a Package.swift, plus the SPM step in your project. Today this is all it takes:
use objc2_ui_kit::UIView;
let view: &UIView = unsafe { &*ui_view.cast::<UIView>() };
let raw = view.safeAreaInsets();How does the platform call us back?
So far this is just rust calling into the platform. The other direction is what most of the protobuf and swift-bridge machinery was there for.
With objc2 we can define an Objective-C class in rust and hand it to UIKit as a delegate:
define_class!(
#[unsafe(super(NSObject))]
#[name = "BevyIosNotificationsDelegate"]
struct Delegate;
unsafe impl UNUserNotificationCenterDelegate for Delegate {
#[unsafe(method(userNotificationCenter:willPresentNotification:withCompletionHandler:))]
fn will_present(
&self,
_center: &UNUserNotificationCenter,
notification: &UNNotification,
completion_handler: &DynBlock<dyn Fn(UNNotificationPresentationOptions)>,
) {
send_event(IosNotificationEvents::NotificationTriggered(
notification.request().identifier().to_string(),
));
let options = UNNotificationPresentationOptions::Banner
| UNNotificationPresentationOptions::List
| UNNotificationPresentationOptions::Badge
| UNNotificationPresentationOptions::Sound;
completion_handler.call((options,));
}
// ...
}
);
The delegate above sends the Event off and calls the completion handler. send_event is our own little helper on top of bevy_channel_message, it grabs the sender that our plugin put in place when it was built. So our Events end up in Bevy just like before.
All in all we deleted 2809 lines from bevy_ios_notifications, 1615 of them a single generated Data.pb.swift file. bevy_ios_gamecenter lost 4430 lines!
Remember the push notification token from the deep-linking post? It is done now.
Those tokens are only handed to the UIApplicationDelegate, so instead of swizzling from Swift we add those two callbacks to whatever delegate the app has and install our own if there is none. If bevy_ios_app_delegate already set one up we hook into that one.
What changes for you
You don't have to add an SPM package anymore, no linking GameKit or StoreKit by hand and no screenshots in the README. There is just one version left to get right instead of two.
And bevy_ios_gamecenter and bevy_ios_iap build for the simulator again.
What about StoreKit 2?
bevy_ios_iap is the one exception. StoreKit 2 is Swift only, there is no Objective-C runtime for objc2 to bind against, so here we are back to writing the bridge ourselves.
So this crate keeps a small Swift shim. But that shim now lives inside the crate: build.rs compiles it with swiftc and links it statically.
The two sides talk over a hand-written C ABI carrying JSON.
Not pretty, but you still just cargo add bevy_ios_iap - no SPM package, no .xcframework release. This one is on main and not released yet.
Releases
| crate | version |
|---|---|
| bevy_ios_alerts | 0.9 |
| bevy_ios_gamecenter | 0.7 |
| bevy_ios_notifications | 0.8 |
| bevy_ios_review | 0.7 |
| bevy_ios_safearea | 0.7 |
| bevy_ios_iap | 0.11 (unreleased) |
Conclusion
We did not change the public APIs much, bevy_ios_notifications is the exception here so check its changelog. If you are using any of these crates go and delete the SPM dependency from your xcode project and bump the rust one.
Thanks to the objc2 crate for making all of this possible. Adding an iOS crate to your bevy game is just cargo add now!
